Audio input -

XLR-3-pin (female) (x 2), line/mic/mic +48 V selectable

Mic: -8 dBu to -65 dBu (reference level)

Line: +4 dBu

A/V output -

AV multi (x 1)

Audio: -10 dBu (reference level), 47 kΩ

Analogue composite: 1.0 Vp-p, 75 Ω unbalanced

S-Video: Y: 1.0 Vp-p, 75 Ω unbalanced, sync negative

Component output - Mini D (x 1), Y: 1.0 Vp-p, 75 Ω, Pb/Pr: 0.7 Vp-p, 75 Ω

SDI output - BNC (x 1), HD-SDI/SD-SDI selectable

i.LINK input/output - IEEE1394, 4-pin (x 1), HDV stream input/output, S400

USB - Mini-B (x 1), USB 2.0 High-speed

Headphone output - Stereo mini-jack (x 1), 16 Ω, 30 mW

Speaker output - Monaural, 300 mW

DC input - DC jack

Battery input - 5-pin

Built-in LCD monitor - 3.5-inch* type colour LCD monitor, approx. 921000 effective pixels, 640 (H) x 3 (RGB) x 480 (V), 16:9, hybrid type

Viewfinder - 0.54-inch* type colour LCD, 1120 (H) x 225 (V), 16:9
