Audio Input -

XLR-type 3-pin (female) (x2), line/mic/mic +48 V selectable

Line: +4dBu

Mic: -70dBu--30dBu

Composite Output - AV multi connector, NTSC or PAL

Video Output - BNC (x1), HD-Y/Composite, 1.0Vp-p, 75Ω (switchable to Genlock in)

Audio Output - A/V multi connector, -10dBu (Reference Level), 47kΩ

SDI Output - BNC (x1), HD/SD selectable, SMPTE 292M/259M standards

i.LINK - IEEE 1394, 4-pin (x1), HDV (HDV 1080i) / DV input/output, S400

Timecode Input -

BNC (x1) (switchable to TC out)

SMPTE 12M-2-2008 standard

0.5V-1.8Vp-p, 10kΩ

Timecode Output -

BNC (x1) (switchable to TC in)

SMPTE 12M-2-2008 standard

1.0Vp-p, 10kΩ

Genlock Input - BNC (x1) (switchable to Video out), 1.0 Vp-p, 75Ω

USB - USB device, mini-B (x1)

Headphone Output - Stereo mini jack (x1), -18dBu 16Ω

Speaker Output - Monaural, 250mW

DC Input - DC jack

Lens Remote - 8-pin, round

HDMI Output - Type A (x1)
