Audio Input (CH1) - XLR-type 3-pin (female) (x1)

Audio Input (CH2) - XLR-type 3-pin (female) (x1)

Mic Input - XLR-type 3-pin (female) (x1)

Return Control Input -

6-pin (x1)

BNC (x1), 1.0 Vp-p, 75 Ω

DC Input - XLR-type 4-pin (x1), DC 10.5 V to 17 V

DC Output - 4-pin (x1), DC 10.5 V to 17.5 V, 0.5 A (max.)

Test Output - BNC (x1)

SDI Output - BNC (x1) HD-SDI or SD-SDI selectable

Earphone Output - Stereo mini jack (x1)

CCU - Triax connector (x1)

Tracker - 10-pin (x1)

Intercom 1 - XLR-type 5-pin (female) (x1)

Remote - 8-pin (x1)

Lens - 12-pin (x1)

Viewfinder - 20-pin (x1)
