Load capacity - 1000kg

Lifting speed - 4m/min

Operating voltage - 230/400V 50Hz - 208/460V 60Hz

Protection Class - IP55

Motorpower at 50Hz - 0,66kW

Current consumption at full load - 1.46amp @ 400V - 2.53amp @ 230V

FEM Class - 1Am

FEM Duty factor - 50%

Starts per hour - 300

Noise Level - 60dBA

Load Wheel - 5 pocket

Load Chain EN 818-7 - 7.1x20.5mm

Falls of chain - 1

Weight of Chain - 1.1kg

Weight of Body - 47kg

Type of Control - DC and LVC

Limit switches - single up/low limit-switches on DC and LVC

Type of Power Connector - CEE 16A-4p (red)

Type of LVC Connector - CEE 10A-4p (yellow)

Low Voltage Control Voltage - 24V
