System Specifications

• Dynamic Range - 80 dB (1 kHz, THD < 1%)

• Frequency Response - 200 Hz – 15 kHz (-3 dB)

• Call Signal (Send) - 2.8 mA

• Call Signal Threshold (Receive) - +2.4V DC

• Operating Voltage - 24-32V DC

Intercom Line

• Impedance - 350 Ω (1 kHz), 2.2 kΩ (DC)

• Audio Level - nom. -18 dBu, max. 0 dBu

Switch Mode Power Supply

• Mains Voltage Range - 100-240V AC, 50-60 Hz

• DC output voltage: +30 V DC (+/-5%)

• Max. output power: 75 watts

• Circuit breaker delay time: 0.2 sec.

• Automatic reset time: 3.0 sec.
